Specifications
- Specifications/Standards: Measurement data output terminal included
- Constant pressure device included
- Measurement range (mm): 25-50
- Minimum display (mm): 0.001
- Maximum permissible error (μm): ±2
- Protection class: IP65
- Power supply: Button-type silver oxide battery (SR44) x 1 (included)
- Manufacturer code: 342-252-30
- Tip angle (°): 15
- Measuring surface shape: Point type
- Constant pressure device: Ratchet stop
- Power supply (V): Button-type silver oxide battery (SR44) x 1 (Included) a: 10.1
- b: 47
- c: 12.5
- L: 25
- Position detection method: Electromagnetic induction rotary encoder
- Tip angle: 15°
- Minimum display unit (mm): 0.001
- Model number: CPM15-50MX
- Battery life: Approximately 2.4 years under normal use
- Weight/Weight unit: 490g
- Set contents/Accessories: 1 reference rod (excluding measurement range 0-25mm), 1 spanner (No.301336)
- Country of origin: Japan
Note: For US buyers, import duties are included in the price. For buyers outside the US, import duties are not included in the price.
