Specifications
- Specifications/Standards: With constant pressure device
- Measuring surface has carbide alloy tip
- Measuring range (mm): 50-75
- Minimum display (mm): 0.01
- Maximum permissible error (μm): ±2
- Manufacturer code: 102-303
- Measuring surface shape: Standard type
- Constant pressure device: Ratchet stop
- a: 10.6
- b: 45
- c: 2.5
- L: 50
- Parallelism (μm): 2
- Flatness (μm): 0.6
- Graduation (mm): 0.01
- Symbol: M310-100
- Weight/Unit of Mass: 375g
- Set Contents/Accessories: 1 reference rod (excluding measurement range 0-25mm), 1 spanner (No. 301336) (measurement range 0-25mm, 25-50mm), 1 spanner (No. 200877) (measurement range 50-75mm, 75-100mm)
- Country of Origin: Japan
Note: For US buyers, import duties are included in the price. For buyers outside the US, import duties are not included in the price.
