Specifications
- Specifications/Standards: Measurement data output terminal included
- Measurement range (mm): 100-125
- Minimum display (mm): 0.001
- Maximum permissible error (μm): ±2
- Protection class: IP65
- Power supply: Button-type silver oxide battery (SR44) x 1 (included)
- Manufacturer code: 293-250-30
- Measuring surface shape: Standard type
- Constant pressure device: Ratchet stop
- Power supply (V): Button-type silver oxide battery (SR44) x 1 (included)
- a: 16.7
- b : 76
- c: 5.3
- L: 100
- Position detection method: Electromagnetic induction rotary encoder
- Parallelism (μm): 3
- Flatness (μm): 0.3
- Minimum display unit (mm): 0.001
- Measuring force (N): 5~10
- Model number: MDC-125MX
- Battery life: Approximately 2.4 years under normal use
- Weight/Weight unit: 600g
- Set contents/Accessories: 1 reference rod, 1 spanner (No.301336)
- Country of origin: Japan
