Specifications
- Specifications/Standards: Measuring surface with carbide tip
- Constant pressure device included
- Measuring range (mm): 75-100
- Minimum display (mm): 0.01
- Maximum permissible error (μm): ±3
- Manufacturer code: 103-140
- Measuring surface shape: Standard flat type (with carbide tip)
- Constant pressure device: Ratchet stop
- Minimum display: 0.01mm
- b: 60
- c: 2.5
- L: 75
- Parallelism (μm): 3
- Flatness (μ m): 0.6
- Measuring force (N): 5~10
- Graduation (mm): 0.01
- Symbol: OM-100
- Weight/Unit of mass: 0.375 kg
- Set contents/Accessories: 1 reference rod (excluding measuring range 0~25 mm), 1 spanner (No. 301336) (maximum measuring length 300 mm or less), 1 spanner (No. 200154) (maximum measuring length 325 mm or more)
- Country of origin: Japan
